ATEN Seamless Presentation Switch with Quad View Multistreaming VP2120

ATEN Seamless Presentation Switch with Quad View Multistreaming VP2120

• מיני ממתג בעל כניסת HDMI אחת + 4 מקורות שונים ב IP ל-2 יציאות HDMI המאפשרים תצוגת כל מקור בנפרד או בתצורת Quad, כולל שליטה באודיו (DSP) ולוח כתיבה שיתופי מובנה
• תומך באפליקציית בקרת מצגת וידאו ATEN לשיתוף פעולה נוח ושליטה במצגות פגישות באמצעות המכשיר הנייד שלך
• סטרימינג של תוכן אלחוטי דו-כיווני של עד 4 משתתפים בו זמנית עם תמיכה בצפייה מרובעת
• מובנה שמע DSP – משלב קלט מיקרופון, כניסת HDMI, וכניסת הזרמת האחרונה עבור HDMI או פלט שמע
• פונקציות מתקדמות לשיתוף רעיונות מקוונות – לוח ציורים, חדר צ'אט, שיתוף קבצים, שידור קבוצתי וצילום וידאו



—–

The VP2120 is a Seamless Presentation Switch that integrates video matrix switch, quad-view multistreaming, audio DSP, and idea-sharing platform into one compact device. With the seamless switching between streamed-in sources, the online idea exchanging features, and the network capability that enables the wireless connection for mobile devices, the VP2120 and ATEN Video Presentation Control App empower wireless BYOD collaboration anytime when a short catch-up, quick meeting, instant brainstorm, stand-up, or ad hoc call is needed.

Designed for flexible and spontaneous team collaboration, the VP2120 along with ATEN Video Presentation Control App facilitates BYOD meetings with the straightforward user interface that give users quick and easy access to any on-the-fly meetings. Joining an online meeting is easy and secure. Participants can just bring their own devices and use the private QR code or room code, or auto scan the local network to get available room list to log in, even when they’re not physically in the same area. The VP2120 allows bi-directional content streaming of up to 4 participants simultaneously. With the built-in multi-view mode, the streamed sources can be displayed on the same screen, which the layout dynamically adjusts to suit the number of sources available. Participants can also focus a streaming input to display full screen or view the go-live screen together for synchronization. As long as the participants are all in the same network environment, the built-in audio DSP enables the remote one to broadcast microphone audio signal to other meeting members, as well as mixes Mic input and HDMI input for HDMI or audio output.

The VP2120 along with ATEN Video Presentation Control App also features more advanced online idea-sharing functions: Whiteboard allows real-time annotation for idea exchange and synchronization; Chat Room feature enhances interaction between participants; File Sharing enables further data sharing and follow-up; while Video Capture records the meeting process for future tracking. This Collaborative presentation solution facilitates any forms of small-group discussion that gives an immediate boost to team work.

• Brilliant AV Routing
  • One HDMI input and dual HDMI outputs plus 4 bi-directional streaming with matrix display support
  • Seamless Switching between streamed-in sources for fast idea exchange
  • Scaler – features a video scaling function to convert input resolutions to the optimum display resolutions
  • Audio DSP – mixes Mic input and HDMI input for HDMI or audio output
  • HDMI audio de-embedding support

• Launch a Quick Meeting Anytime
  • Launches wireless BYOD collaboration via Web GUI and Mobile App in a swift and agile way
  • Offers quick and easy access to log in a quick meeting via multiple methods:
    . Start auto scan and select a room number from the list
    . Scan the QR code shown on the VP2120 OSD
    . Load a pre-saved QR code
    . Input the IP address and Room code shown on the OSD

• Seamless BYOD Collaboration
  • Multiple control method via front-panel pushbuttons, web GUI, OSD, IR remote, and mobile App
  • Streaming in – view up to 4 streamed-in contents simultaneously for real-time synchronization
  • Streaming out – allows log-in participants to view the Go-live contents on personal devices
  • Multi-view with Auto layout – dynamically adjusts the layout to suit the number of streamed-in sources available
  • Whiteboard allows real-time annotation for idea exchange and synchronization
  • Chat room feature enhances text interaction and information sharing
  • Video capture records the meeting process for future tracking
  • File sharing enables further data sharing and follow-up

• High-definition Video with Optimum Output
  • Superior video quality up to 1920 x 1080 with single streaming input and 854 x 480 with four streaming inputs
  • EDID Expert™ – automatically selects the optimum EDID settings for smooth power-up, high-quality display, and the best video resolution across connected devices
  • HDMI (1080p); CEC (Consumer Electronics Control); HDCP 1.4 compliant



לכניסה לפירוט הדגם המלא באתר היצרן לחצו כאן
